Ullage Temperature Interface (UTI) Supplier
Reliable UTI Solutions for Safe and Compliant Marine Operations
DM SAFETY
Our SERVICES
DM Safety supplies, calibrates, and services Ullage Temperature Interface (UTI) systems designed for precise measurement of ullage level, cargo temperature, and oil-water interface onboard tankers and marine vessels. Our UTI solutions support safe cargo operations, accurate quantity calculations, and full compliance with IMO, SOLAS, Class, and Flag State requirements.
Engineered for hazardous marine environments, UTIs supplied and serviced by DM Safety feature intrinsically safe design, anti-static tapes, grounding systems, and high-accuracy sensors. Whether for crude oil tankers, chemical carriers, offshore platforms, or storage tanks, our UTI systems deliver reliable performance even under harsh operating conditions such as vapor exposure, temperature extremes, and vessel movement. We provide supply, calibration, certification, repair, and annual maintenance of UTI systems across the UAE, ensuring vessels remain inspection-ready and operational at all times.
WHAT IS AN ULLAGE TEMPERATURE INTERFACE (UTI)?
An Ullage Temperature Interface (UTI) is a portable marine gauging instrument used to measure ullage (empty space in the tank), cargo temperature, and the oil-water interface level. UTIs are widely used onboard oil tankers, chemical tankers, offshore vessels, and storage tanks to accurately determine cargo quantity, detect water contamination, and ensure safe and precise loading and discharge operations. UTI systems typically consist of:
- Sensor probe
- Winding drum
- Display/control unit
- Grounding cable for safe operation
- Anti-static measuring tape (15 m – 40 m)
TYPES OF ULLAGE TEMPERATURE INTERFACE (UTI) SYSTEMS
Closed Type UTI
- Gas-tight design to prevent vapor escape
- Used with vapor control valves
- Suitable for hazardous cargo tanks
- Recognized as equivalent to fixed gauging systems when used correctly
Open / Restricted Type UTI
- Direct tank access for measurement
- Multi-mode operation (ullage, temperature, interface)
- Simple and efficient for routine gauging
Accessories & Components
- Anti-static measuring tapes
- Grounding cables with safety clamps
- Replacement probes and display units
- Calibration and testing equipment
Technical Specifications
The Ullage Temperature Interface (UTI) is a versatile measurement device engineered for marine and offshore applications, offering precise monitoring of ullage, cargo temperature, and oil-water interfaces. Available with tape lengths ranging from 15 m to 40 m and customizable options, it is suitable for the diverse operational needs of oil tankers, chemical tankers, and offshore vessels. Its high-precision, marine-grade sensors provide reliable readings across a wide temperature range of –40°C to +110°C, ensuring performance even in harsh marine environments.
Safety and regulatory compliance are core to the UTI design. The device is intrinsically safe, anti-static, and must be properly grounded to maintain operational integrity. It includes a digital display with audible alerts for easy reading and real-time notifications. Fully compliant with IMO, SOLAS, and applicable Class and Flag State standards, the UTI supports annual calibration, guaranteeing continued measurement accuracy and regulatory adherence.
In addition to its core measurement capabilities, the UTI offers flexible service and maintenance options to minimize downtime and maximize operational efficiency. DM Safety provides on-site, port-side, and workshop calibration and repair services, ensuring vessels remain compliant and operational at all times.
| Parameter | Values / Range |
|---|---|
|
Measurement Functions |
Ullage, Temperature, Oil-Water Interface |
|
Tape Length |
15 m – 40 m (custom options available) |
|
Temperature Range |
–40°C to +110°C |
|
Accuracy |
High-precision marine-grade sensors |
|
Safety |
Intrinsically safe, anti-static, grounding required |
|
Display |
Digital display with audible signals |
|
Application |
Oil tankers, chemical tankers, offshore vessels |
|
Compliance |
IMO, SOLAS, Class & Flag State standards |
|
Calibration Interval |
Annual calibration recommended |
HOW DOES IT WORK?
Ullage Detection
The UTI probe emits ultrasonic signals when it reaches the cargo surface. Once contact is detected, the system produces a continuous audible signal, allowing operators to accurately determine the ullage level even in challenging marine conditions.
Temperature Measurement
UTIs use a Platinum Resistance Temperature Detector (RTD) to measure cargo temperature. The sensor signal is digitized and processed by a micro-controller within the probe, ensuring high accuracy and compensation for environmental variations.
Oil-Water Interface Detection
The interface function works by measuring electrical conductivity. When the probe reaches water (conductive), the system emits an intermittent signal, clearly distinguishing oil from water layers inside the tank.
KEY BENEFITS
Accurate Measurement
Ensures precise ullage and temperature readings for safe cargo handling and monitoring.
Interface Detection
Reliably identifies the oil-water boundary to prevent contamination and cargo loss.
Intrinsically Safe Design
Safe for use in hazardous marine zones with anti-static and grounding features.
Cargo & Custody Accuracy
Supports correct cargo calculations and custody transfer documentation.
Regulatory Compliance
Meets IMO, SOLAS, Class, and Flag State marine safety requirements.
WHY CHOOSE DM SAFETY?
Marine Expertise
Trusted marine fire & safety and instrumentation provider in Dubai and the UAE.
Certified Compliance
Annual calibration and certification in line with IMO, SOLAS, Class, and Flag State requirements.
Multi-Brand Support
Service and calibration for leading UTI brands and models.
End-to-End Services
Supply, installation support, calibration, repair, maintenance, and documentation.
Fast Turnaround
Quick service to minimize vessel downtime.
On-Site & Workshop Support
Flexible service options for vessels, ports, and offshore facilities.
OPERATION & MAINTENANCE
Before use, the UTI system must be properly grounded to the tank. The probe is then lowered gradually using the measuring tape to detect ullage, temperature, or interface level. Audible and visual signals guide the operator for precise readings. To maintain accuracy and safety:
- Annual calibration is mandatory
- Sensors and tapes should be inspected regularly
- Batteries and grounding cables must be checked
- Damaged probes or tapes should be replaced immediately
DM Safety provides scheduled maintenance and calibration programs to ensure continuous compliance and operational reliability.
